Description
Engine
Engine Type: Inline 2-Cylinder E-TEC D.I.
Bore x Stroke: 2.992 x 2.5 in. (76 x 64 mm)
Displacement: 35.2 cu.in. (577cc)
Starting: Electric and Rope
Dimensions
Shaft Length: 25 in. (635 mm)
Weight: 184 lb. (84 kg)
General
Trim Method: High Speed Power Tilt
Propshaft Horsepower: 15 hp
Full Throttle Operating Range: 5000-5500 rpm
Gear Ratio / Shift: 2.15:1
Fuel Induction: E-TEC Direct Injection with stratified low RPM combustion mode
Alternator: 56 Amps Total / 15 Amps Net Dedicated
Steering: Remote (Tiller avail.)
Warranty: 3-Year, Non-Declining
Features
High Output Series: The Evinrude E-TEC H.O. series are performance engines to the max. Each engine is tuned for extra power and speed. If you like pushing limits in horsepower, speed and torque, then consider our High Output Series.
Auto-Storage: The auto winterization feature fogs the engines itself in minutes, with no trip to the dealer. An Evinrude E-TEC engine does not require belts, camshafts or exhaust valves, which means there are fewer parts to wear down or malfunction than a four–stroke outboard. Extend the life of your outboard and your boating season.
More Miles Per Hour: Get even more extra miles per hour with the Straight Leading Edge gearcase. The Evinrude SLE gearcase features high-efficiency water pickups and a weed-slicing shape up front, for a cooler-running engine and ultimate durability and reliability in the long run.
Specifications
Engine Model: E15HPGX Graphite
Engine Type: Inline 2-Cylinder E-TEC D.I.
Bore x Stroke – in (mm): 2.992 x 2.5 (76 x 64)
Displacement – cu in (cc) L: 35.2 (577)
Gear Ratio: 2.15:1
Full Throttle RPM Range: 5000-5500 RPM
Weight – lbs (kg): 184 (84)
Starting: Electric and Rope
Controls: Mechanical
Fuel Induction: E-TEC Direct Injection with stratified low RPM combustion mode
Alternator Output*: 56 Amps Total / 15 Amps Net Dedicated
Steering: Remote (Tiller avail.)
Trim Method: High Speed Power Tilt
Trim Range: -6″ to 15″
Tilt Range: 75°
Shaft Length – in (mm): 25 (635)
Lubrication: Multi-Point Targeted Oiling
Oil Tank Capacity – gal (L): 1.7 (1.6)
Recommended Oil: Evinrude / Johnson XD-100 Oil
Recommended Fuel: 87 Octane
Warranty: 3-Year, Non-Declining
Emissions Compliance: EPA 2013 / CARB 3 STAR / European Union
